DTS-22
Product Description
DTS-22 is a high-performance tactical head mounted night vision binocular built by Detyl Optoelectronics.
Low light version dts-22 has the characteristics of super large field of view, high definition, no distortion, light weight, high strength (the overall performance is much better than the original version of the U.S. products), which is the ideal choice for night vision equipment.
| MODEL | DTS-22 |
| Structural mode | Arbitrary turn it over |
| rollover detection | Automatically detect and power off when turning up |
| Battery type | Lithium battery (cr123x1) / cr23x4 external battery box |
| Power supply | 1.2-1.6V |
| Installation | Head mounted(standard American helmet interface) |
| control mode | ON/IR/AUTO |
| Over power consumption | <0.1W |
| Battery capacity | 300-3200maH |
| Battery life | 30-100H |
| magnification | 1X |
| FOV( °) | 50 +/-1 |
| Parallelism of optical axis | <0.5 ° |
| IIT | Gen2+/3 |
| Lens system | F1.18 22.5mm |
| MTF | 120LP/mm |
| Optical distortion | 1% Max |
| Relative Illumination | >75% |
| coating | Multilayer broadband coating |
| Range of focus | 250mm-∞ |
| Focus mode | manual focus facility |
| Distance of pupil | 30-35mm |
| Eyepiece aperture | 9mm |
| Range of visibility | 0 (+ / - 5 optional) |
| Eye spacing adjustment | Arbitrary continuous adjustable |
| IR | 850nm 20mW |
| Operating temperature | -40--+55ºC |
| Relative humidity | 5%-95% |
| Environment rating | IP65/IP67 |
| Dimensions | 80x132x81 |
| weight | 430G(no battery) |
Product Description
DTS-22 is a high-performance tactical head mounted night vision binocular built by Detyl Optoelectronics.
Low light version dts-22 has the characteristics of super large field of view, high definition, no distortion, light weight, high strength (the overall performance is much better than the original version of the U.S. products), which is the ideal choice for night vision equipment.
| MODEL | DTS-22 |
| Structural mode | Arbitrary turn it over |
| rollover detection | Automatically detect and power off when turning up |
| Battery type | Lithium battery (cr123x1) / cr23x4 external battery box |
| Power supply | 1.2-1.6V |
| Installation | Head mounted(standard American helmet interface) |
| control mode | ON/IR/AUTO |
| Over power consumption | <0.1W |
| Battery capacity | 300-3200maH |
| Battery life | 30-100H |
| magnification | 1X |
| FOV( °) | 50 +/-1 |
| Parallelism of optical axis | <0.5 ° |
| IIT | Gen2+/3 |
| Lens system | F1.18 22.5mm |
| MTF | 120LP/mm |
| Optical distortion | 1% Max |
| Relative Illumination | >75% |
| coating | Multilayer broadband coating |
| Range of focus | 250mm-∞ |
| Focus mode | manual focus facility |
| Distance of pupil | 30-35mm |
| Eyepiece aperture | 9mm |
| Range of visibility | 0 (+ / - 5 optional) |
| Eye spacing adjustment | Arbitrary continuous adjustable |
| IR | 850nm 20mW |
| Operating temperature | -40--+55ºC |
| Relative humidity | 5%-95% |
| Environment rating | IP65/IP67 |
| Dimensions | 80x132x81 |
| weight | 430G(no battery) |
